TIMKEN E-P2B-TRB-2 PILLOW BLOCK BEARING UNIT
Quick Overview
Manufactured By: TIMKEN
Manufacturer Part Number: E-P2B-TRB-2
IMS Product Code: 1792299
Packaging: Sold Individually
Description:
Timken E-P2B-TRB-2 Pillow Block Bearing Unit
Specifications:
- Bore Diameter: 2"
- Expansion Type: Non-Expansion Bearing (Fixed)
- Overall Length: 8.875"
- Finish/Coating: E-Coat
- Overall Height: 4.5"
- Overall Width: 3.5"
- Mounting: Two-Bolt Base
- Seal Type: Triple Barrier Seal
- Bearing Type: Tapered Roller
- Base Height: 1.3125"
- Bore Type: Round
- Radial Dynamic Load Capacity: 10300 lb
- Housing Construction: Solid Pillow Block
- Maximum RPM: 2590 RPM
- Base To Bore Centerline: 2.25"
- Operating Temperature Range: -30 to +180 °F
- Duty Type: Heavy Duty
- Lubrication Type: Lubrication Fitting
- Housing Material: Cast Iron
- Radial Static Load Capacity: 43000 lb
- Locking Device: Concentric Collar
- Bolt Size: 0.625"
- Bearing Material: Bearing Steel
- Bolt Center-To-Center Length: 7"
- Base Width:2.5"
