TERRAWAVE SOLUTIONS TW-SP-1GBPS-10-1T SINGLE PORT ETHERNET

Call For Quote

Quick Overview

Manufactured By: TERRAWAVE SOLUTIONS
Manufacturer Part Number: TW-SP-1GBPS-10-1T
IMS Product Code: 1765784
Packaging: Sold Individually

Description:

TerraWave Solutions TW-SP-1GBPS-10-1T   Single Port Ethernet Surge Suppressor

Specifications:

  • Operating Voltage: Data: 5V     PoE: 48V
  • Break Down Voltage: Data: 90V  PoE: 90V
  • Impulse Protected Voltage: <250V
  • Max Surge Discharge Current: (8/20uS): 10KA
  • Peak Pulse Current: 100A (10/1000uS)
  • Max Shunt Capacitance: Power & Data: <2.5pF
  • Insulation Impedance: ≥ 1000M Ohm
  • Data Rate: 1000 Mbps
  • Response Time: <5 nS
  • Ground Wire: 14 AWG
  • Dimensions (w/ bracket)
  • 4.7" (L) x 1.0" (W) x 1.0" (H)
  • Weight: 0.23 lbs
  • Operating Temperature Range: -40°F to +185°F
  • Storage Temperature Range: -40°F to +257°F
  • Operating Humidity: 0-95% non-condensing
