TECHNIKS 8168812 A20T-PCLNR-4 (1-1/4"-S-BB-CT-RH)
Starting At: $184.30
Quick Overview
Manufactured By: TECHNIKS
Manufacturer Part Number: 8168812
IMS Product Code: 1779639
Packaging: Sold Individually
Description:
Techniks 8168812 A20T-PCLNR-4 (1-1/4"-S-BB-CT-RH), Right Hand 1.25" Diameter Boring Bar uses CNMG 43_ Size Insert Coolant Through
Specifications:
- DESIGNATION: A20T-PCLNR-4 (1-1/4"-S-BB-CT-RH)
- UNSPSC Code: 23242106
- GRADE: N/A
- CHIP BREAKER: N/A
- IC: N/A
- THICKNESS: N/A
- RADIUS: N/A
- CHAMFER WIDTH: N/A
- HEIGHT: 1.25
- LENGTH: 12
- HOLDER ANGLE: 95
- MIN. BORE DIA.: 1.46
- CUTTING DIAMETER: N/A
- ARBOR or SHANK DIAMETER: N/A
- SHANK LENGTH: N/A
- ASPECT RATIO: N/A
- MATERIAL: Steel
- COATING: N/A
- HOLDING SYSTEM: Lever
- GAUGE INSERT: CNMG 432
- GAUGE INSERT (external): N/A
- GAUGE INSERT (internal): N/A
- CHIP BREAKER FUNCTION: N/A
- IPR (min): N/A
- IPR (max): N/A
- DOC (min): N/A
- DOC (max): N/A
- IPT (min): N/A
- IPT (max): N/A
- CUTTER or SHANK: N/A
- SHANK STYLE: N/A
- MAX Ap (DOC): N/A
- CUTTER APPROACH ANGLE: N/A
- COOLANT THRU: Yes
- NUMBER OF TEETH: N/A
- INTERNAL or EXTERNAL: N/A
- WEIGHT PER PIECE: 3.8
- QTY PER BOX: N/A
- CLAMP: N/A
- CLAMP SCREW: N/A
- SHIM: 9333252
- SHIM SCREW: N/A
- WRENCH: 9322121
- SHIM PIN: 9333999
- SCREW: 9345333
- LEVER: 9335333
Direct From Manufacturer:
A new product, shipped directly from the manufacturer.
Lead Time: 7 to 21 Days
