TECHNIKS 46.122.40.315 SCAT 40 X ER 40 - 3.15" DUAL DRIVE

MSRP: $279.00
Starting At: $265.05

Quick Overview

Manufactured By: TECHNIKS
Manufacturer Part Number: 46.122.40.315
IMS Product Code: 1763565
Packaging: Sold Individually

Description:

Techniks 46.122.40.315 SCAT 40 x ER 40 - 3.15" Dual Drive

Specifications:

  • UNSPSC Code     27112807
  • Collet Series     ER40
  • Body Dia-Workpiece Side (in)     2.48
  • Body Dia-Workpiece Side (mm)     63
  • Gage Length (in)     3.15
  • Gage Length (mm)     80.01
  • Gage Length-Face Contact (in)     3.02
  • Gage Length-Face Contact (mm)     76.8
  • Lock Nut Diameter (in)     2.48
  • Lock Nut Diameter (mm)     63
  • Overall Length (in)     5.83
  • Overall Length (mm)     148.1
  • Material     8620 Steel
  • Taper     CAT40
  • Overall Diameter (in)     2.5
  • Overall Diameter (mm)     63.5
  • Unit of Tool     Metric or Inch
  • Type     DualDRIVE Collet Chuck
  • Style     Single Ended DualDRIVE
  • Capacity Range (in)     0.086" - 1.02"
  • Capacity Range (mm)     2.2 - 26mm
  • Balanced to     25,000 RPM at G2.5

Direct From Manufacturer:
A new product, shipped directly from the manufacturer.

Lead Time: 7 to 21 Days

IMS Supply is an authorized Techniks distributor.
