PARLEC H63-20ERP406 ER 20 CHK POWER X 4.06" BALANCED HSK63
Starting At: $388.55
Quick Overview
Manufactured By: PARLEC
Manufacturer Part Number: H63-20ERP406
IMS Product Code: 1741169
Packaging: Sold Individually
Description:
Collet System: ER
Collet Series: ER20
Taper Size: HSK63A
Shank Type: Taper Shank
Projection (Decimal Inch): 4.0600
Minimum Collet Capacity (Decimal Inch): 0.0394
Minimum Collet Capacity (mm): 1.00
Maximum Collet Capacity (mm): 13.00
Maximum Collet Capacity (Decimal Inch): 0.5118
Actuator Type: Wrench
Type: ER Coolant Collet
Nose Diameter (Decimal Inch): 1.3400
Balanced to (RPM): 25000
TIR (Decimal Inch): 0.0002
Coolant Type: Through-Spindle
Collet Nut Diameter (Decimal Inch): 1.3400
Direct From Manufacturer:
A new product, shipped directly from the manufacturer.
Lead Time: 7 to 30 Days
