PANASONIC MKDET1105P AC SERVO DRIVE
Starting At: $588.90
Quick Overview
Manufactured By: PANASONIC
Manufacturer Part Number: MKDET1105P
IMS Product Code: 1971033
Packaging: Sold Individually
Description:
Panasonic MKDET1105P AC Servo Drive, Pulse, A6 Series, E Series, K-Frame, Single Phase Input, Supply Voltage 100VAC, Rated Output Current 10A, Current Detector 5A
Specifications:
- Functions:
(Control method) IGBT PWM Sinusoidal wave drive
Connection to external regenerative resistor
Built in dynamic brake
High-speed position control
Speed control
High-functionality positioning control
Combined position/speed control - Type of network: Single phase input
- Compliant with standard(s):
EN55011
EN61000-6-2
EN50178
IEC61000-4-3
IEC61000-4-4
IEC61000-4-5
IEC61000-4-6
IEC61000-4-11 - Digital inputs:
7 x control signal inputs
2 x pulse signal inputs - Digital outputs:
4 x control signal inputs
4 x pulse signal outputs - Operating mode: pulse
Direct From Manufacturer:
A new product, shipped directly from the manufacturer.
Lead Time: 3 to 30 Days
