PANASONIC FD-L30A DIFFUSE CONVERGENT FIBER OPTIC CABLE
Starting At: $172.58
Quick Overview
Manufactured By: PANASONIC
Manufacturer Part Number: FD-L30A
IMS Product Code: 1972920
Packaging: Sold Individually
Description:
Panasonic FD-L30A Diffuse Convergent Fiber Optic Cable, Front Sense, 0 to 43 mm Sensing Distance, 3m R2 High-Flex Cuttable Cable, Convergent Fiber Optic Cable for Glass Substrate Detection, Ultra-slim Design is Only 3.8 mm Thick, Features Convergent Reflective Design for Alignment of LCD Glass, Sensing Distance of 0 to 43 mm, 3 Meter Free Cut Fiber Optic Cable 2mm Bending Radius
Specifications:
- Series: FT/FD/FR
- Key Characteristics: Limited Distance
- Sensing Mode: Convergent
- Key Attributes: Front Sensing
- Lens Compatible: Not Compatible With Add-On Lens
- Mounting Body Style: Square/Rectangular
- Mounting Dimension: 20mm x 29mm x 3.8mm
- Fiber Cable Feature: Sensing Distance is limited to a specific range and is not easily affected by the background. Works Well for Glass Substrate Detection and Alignment Applications.
- Fiber Cable Bend Radius: R2 High-flex
- Cuttable / Non-Cuttable: Cuttable
- Fiber Length: 3 meter
- Fiber Core: Ø 2.5mm
- Temperature Rating: 0 to +70° C
- Includes: FX-AT5 grey attachment w/tips for Ø1.0mm cuttable fibers, and cutter
Direct From Manufacturer:
A new product, shipped directly from the manufacturer.
Lead Time: 3 to 30 Days
