PANASONIC FD-H25-L43 CONVERGENT FIBER OPTIC CABLE
Starting At: $669.83
Quick Overview
Manufactured By: PANASONIC
Manufacturer Part Number: FD-H25-L43
IMS Product Code: 1972850
Packaging: Sold Individually
Description:
Panasonic FD-H25-L43 Convergent Fiber Optic Cable, Flat Type, Front Sense, High-Temp Rated to 250°C, 3m Non-Cuttable Cable, For Glass Substrate Sensing, High-Temp Rated to 250°C, 3 Meter Non Cuttable Fiber Cable
Specifications:
- Series: FT/FD/FR
- Key Characteristics: Heat-resistant
- Sensing Mode: Convergent
- Key Attributes: Front Sensing
- Lens Compatible: Not Compatible With Add-On Lens
- Mounting Body Style: Square/Rectangular
- Mounting Dimension: 21mm x 32.2mm x 5mm
- Fiber Cable Feature: Features wide temperature range for use in severe temperture enviroments For Glass Substrate Detection SUS Sheath Provides Fiber Cable Protection
- Fiber Cable Bend Radius: R25
- Cuttable / Non-Cuttable: Non-Cuttable w/ SUS Jacket
- Fiber Length: 3 meter
- Fiber Core: Ø 1.2mm core / Ø 1.5 core
- Temperature Rating: -20 to +250° C
- Includes: FX-AT2 orange attachment
- Item Weight: 1.00 lbs per EA
Direct From Manufacturer:
A new product, shipped directly from the manufacturer.
Lead Time: 3 to 30 Days
