ORIENTAL MOTOR PWAM6H010RA MOTORIZED CYLINDER

MSRP: $1,060.00
Starting At: $690.00

Quick Overview

Manufactured By: ORIENTAL MOTOR
Manufacturer Part Number: PWAM6H010RA
IMS Product Code: 1737911
Packaging: Sold Individually

Description:

Specifications

Motor Type

 Motorized Cylinder


Actuator Frame Size

 5.12 in. x 3.43 in.


Power Supply

 Single-Phase 100-115 VAC


Frequency

 50 Hz
60 Hz


Current

 6.4 A


Guide

 Built-in


Electromagnetic Brake

  		 Not Equipped


Lead

 0.1969 in.


Stroke

 3.94 in.


Drive Method

 Ball Screw + Gear


Max. Speed

 7.87 in/s


Thrust

 225 lb (up to 1.97 in/s)
45 lb (up to 7.87 in/s)


Push Force

 ~135 (up to 0.24 in/s)


Max. Horizontal Transportable Mass

 220 lb


Resolution

 0.0004 in.


Repetitive Positioning Accuracy

 ±0.0008 in.


Controller Included

 No


RoHS Compliant

  		 No


Insulation Resistance (Actuator)

 100 M Ω or more when 500 VDC megger is applied between the Motor case - Motor/Sensor windings.


Insulation Resistance (Controller)

 100 M Ω or more when 500 VDC megger is applied between the following:
I/O connector - Main power supply terminal, Motor Connector, Battery Connector
Control power supply terminal - Main power supply terminal, Motor connector, Battery connector
PE - Main power supply terminal, Motor connector, Battery connector


Dielectric Strength (Actuator)

 Sufficient to withstand the following for 1 minute:
Motor case - Motor/Sensor windings 1.5 kVAC 50 Hz


Dielectric Strength (Controller)

 Sufficient to withstand the following for 1 minute:
Signal I/O, Control power supply - Main power supply 1.8 kVAC
Signal I/O, Control power supply - Motor output 1.8 kVAC
Signal I/O, Control power supply - Battery input 1.8 kVAC
PE - Main power supply 1.5 kVAC
PE - Motor output 1.5 kVAC
PE - Battery input 1.5 kVAC


Ambient Temperature Range

 32°F ~ 104°F (0°C ~ 40°C) (nonfreezing)


Ambient Humidity

 85% or less (noncondensing)


Sensor Specifications

Sensor Model

 EE-SX671A (OMRON)


Sensor Power Supply

 5 to 24 VDC ± 10%, ripple (p-p) 10% or less


Current Consumption

 35 mA or less


Control Output

 NPN open-collector output, 5 to 24 VDC, 100 mA or less. Residual voltage 0.8 V or less (at load current of 100 mA)


Indicator LED

 Detection display (red)


Logic

 Normally open/normally closed (switchable, depending on connection)


Sensor Type

 Photomicro sensor


Quantity

 3 pieces, included


Movement

 Possible

New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.

Availability: 2 In Stock

Ships on Monday, November 25, 2024

Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.


Product images shown are for illustration purposes only and may not be an exact representation of the product you will receive. IMS Supply is not an authorized distributor, reseller or representative of Oriental Motor. All product names, trademarks, brands and logos used on this site are the property of their respective owners and are used for identification purposes only.
