OPTEX KR-250CP STAINLESS STEEL ENCASED POLARIZED RETRO-REFLECTIVE
Quick Overview
Manufactured By: OPTEX
Manufacturer Part Number: KR-250CP
IMS Product Code: 1780834
Packaging: Sold Individually
Description:
Optex KR-250CP Stainless Steel Encased Polarized Retro-reflective 2.5M PNP M8 QD
The stainless steel housing helps to protect the sensor against mechanical damage if it is hit by passing objects
The built in mounting nuts make installation easy and efficient, the problems of damaged threads due to overtightening has been eliminated.
The noise resistant internal circuitry is designed in accordance with the strict VDE standard.
Specifications:
| Sensing Mode / Type | Polarized Retro-Reflective |
| Sensing Distance | 2.5 meter |
| Overall Sensing Distance | 0.01 to 2.5 meter |
| Resolution / Min Detectable Object | 40mm min detectable object |
| Light Source | Red LED |
| Supply Voltage | 10 to 30 VDC |
| Current Consumption | 20mA max |
| Response Time | 0.7ms |
| Sensitivity Adjustment | |
| Hysteresis | |
| Output | PNP |
| Output Operation Mode | LO/DO Selectable |
| Material | ABS (case) PMMA (lens) SUS304 (cover) |
| Protection | IP67 |
| Shock Rating | 100G |
| Temperature | -25 to 55° C |
| Special Features | Compact SUS |
| Connection | M8 4 pin QD |
| Includes | Reflector (V-61), mounting bracket/screws |
