MACAIR DX1000A DIGITAL SCROLL DRYER 230V 3PH 60HZ 460V 3PH 60HZ
Quick Overview
Manufactured By: MACAIR
Manufacturer Part Number: DX1000A-230V-3PH-60HZ-460V-3PH-60HZ
IMS Product Code: 1792955
Packaging: Sold Individually
Description:
MACAIR DX1000A Energy Saving Digital Scroll Dryer 230v 3ph 60hz 460v 3ph 60hz
MECHANICAL SPECS
- Inlet Air Flow: 1000 SCFM
- Inlet Temp: 100 / 140 F
- Inlet Pressure: 100 PSIG
- Inlet Temp: 100 F
- DEWPOINT TEMP: 38 F
- COOLING AIR FLOW: 4200
- PRESSURE LOSS, DESIGN: 2.7
- CONDENSER TYPE: Air Cooled
- WEIGHT: 875 LBS
- IN & OUT CONNECTION: 3”
- MAXIMUM ABIENT TEMP: 110 F
- MINIMUM AMBIENT TEMP: 40 F
ELECTRICAL SPECS
- Locked Rotor Amps: 75
- Rated Load Amps: 11
- Max Fuse: 15
- Power Connection: 460-3-60
- Full Load Power (WATTS): 7050
STANDARD FEATURES
- Aluminum block heat exchanger
- Air to air pre-cooler/re-heater
- Stainless Steel Heat Exchanger
- Digital Scroll Compressor
- Closed loop digital controller
- Refrigerant suction and discharge pressure transducers and gauges.
- Heavy duty industrial powder coated steel cabinet
- Environmentally friendly R404a refrigerant
- Refrigerant access ports
- Thermostatic expansion valve
- Filter drier
- Programmable electronic drain valve with y-strainer
- Easy access cabinet design allows for ease for service.
- Allen-Bradley contactors
- Made In USA
OPTIONAL FEATURES
- TTL/RS485 connection for the remote monitoring system MODBUS_RTU compatible.
- Water cooled condenser
- Pre-filter and after-filters mounted on the dryer
- 575-3-60 or 230-3-60 voltages
- Additional pressure and temperature gauges
