LEVITON RDGSW-4CW GREENMAX DIGITAL SWITCH 4 BUTTON LUMACAN3
Quick Overview
Manufactured By: LEVITON
Manufacturer Part Number: RDGSW-4CW
IMS Product Code: 1758602
Packaging: Sold Individually
Description:
Leviton RDGSW-4CW GreenMAX Digital Switch 4 Button LumaCAN3
- RJ45 connectors to provide IN and OUT connections to the LumaCAN network
- California Title 24 2013 compliant when used with GreenMAX Relay Systems
- Any button can be configured to control 0-10VDC dimming circuits
- Easy-to-access port on top of switch provides connectivity for the GreenMAX Handheld Display Unit (HDU)
- Custom engraved labeling available on both switch buttons and wall plates
- Install a mix of GreenMAX Relay Panels, Remote Input Cabinets, and Digital Switches - up to 110 nodes - on a single run of LumaCan
- Switches can be programmed for ON, OFF, ON/OFF, dimmed raise/lower, or single zone preset ON level
- Status LED for each button provides true relay status
- Matching screwless wall plate is supplied and digital switches are compatible with all available Decora® wall plates
- Mounts in a standard depth wall box. All switches can be installed in a multi-gang application. The multi-gang wall plate is sold separately
- Use with GreenMAX Relay Systems
- Available in White, Ivory, Light Almond, Gray. Color Change kit available for Black and Red buttons.
- Draws its power from the LumaCan
- Discontinued
