IFM EFECTOR IZ5026 INDUCTIVE SENSOR
Starting At: $51.75
Quick Overview
Manufactured By: IFM EFECTOR
Manufacturer Part Number: IZ5026
IMS Product Code: 1802230
Packaging: Sold Individually
Description:
IFM Efector IZ5026 Inductive Sensor
Specifications:
Electrical data
- Operating voltage [V]: 10...36 DC; (cULus - Class 2 source required)
- Current consumption [mA]: 15; (24 V)
- Protection class: III
- Reverse polarity protection: yes
Outputs
- Electrical design: PNP
- Output function: normally open
- Max. voltage drop switching output DC [V]: 2.5
- Permanent current rating of switching output DC [mA]: 100
- Switching frequency DC [Hz]: 2000
- Short-circuit protection: yes
- Type of short-circuit protection: yes (non-latching)
- Overload protection: yes
Monitoring range
- Sensing range [mm]: 0.8
- Real sensing range Sr [mm]: 0.8 ± 10 %
- Operating distance [mm]: 0...0.65
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 2 In Stock
Ships on Monday, November 18, 2024
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
