EAGLE SIGNAL HP50A6 030SEC, 120V, 60HZ, TIMER
Quick Overview
Manufactured By: EAGLE SIGNAL
Manufacturer Part Number: HP50A6
IMS Product Code: 1806950
Packaging: Sold Individually
Description:
Eagle Signal HP50A6 030SEC, 120V, 60HZ, Timer
Specifications:
- Accuracy: ±.15 Sec.
- Contact Current Rating: 10 A
- Cut Out, Panel: 3.187 in., 80.95 mm Dia.
- Depth: 0.236" (6mm)
- Dimensions: 96.82 x 107.95 x 146.05 mm
- Display Type: Analog
- Function: Hour, Elasped Time
- Input Signal Type: Power to Contacts
- Length: 3.811" (96.82mm)
- Mounting Style: Panel Mount
- Primary Type: Reset Timer
- Range, Measurement: 0 to 30 sec.
- Series: CYCL-FLEX HP5 Series
- Supply Voltage: 120 VAC
- Temperature, Operating, Maximum: 60 °C
- Temperature, Operating, Minimum: -18 °C
- Temperature, Operating, Range: -18 to +60 °C
- Terminal Type: Screw
- Termination: Screw
- Type: Electric Reset Timer
