BALDOR EM4108T SUPER-E MOTOR 30HP, 3520RPM, 3PH, 60HZ
Quick Overview
Manufactured By: BALDOR
Manufacturer Part Number: EM4108T
IMS Product Code: 1803878
Packaging: Sold Individually
Description:
Baldor EM4108T Super-E Motor 30HP, 3520RPM, 3PH, 60HZ, 286TS, 0950M, TEFC, F
Specifications:
- Output: 30.000 hp
- Phase: 3
- Synchronous Speed: 3,600 rpm
- Frequency: 60.00 Hz
- Voltage: 230 V/ 460 V
- Frame Material: Iron
- Frame: 286TS
- XP Class and Group: NONE
- XP Division: Not Applicable
- Brand: Baldor-Reliance
- Agency Approvals: CSA/CSA EEV/UR
- Ambient Temperature: 40 °C
- Auxillary Box No: Auxillary Box
- Auxillary Box Lead Termination: None
- Base Indicator: Rigid
- Bearing Grease Type: POLYREX EM (-20F +300F)
- Blower: None
- Current: 74.0 A @ 208 V/68.0 A @ 230 V/34.0 A @ 460 V
- Design Code: A
- Drip Cover: No Drip Cover
- Duty Rating: CONT
- Efficiency: @ 100% Load 91.7%
- Electrically Isolated Bearing: Not Electrically Isolated
- Feedback Device: No feedback
- Front Face Code: Standard
- Front Shaft Indicator: None
- Heater Indicator: No heater
- High Voltage Full Load Amps: 34.0 A
- Insulation Class: F
- Inverter Code Inverter: ready
- KVA Code: J
- Lifting Lugs: Standard Lifting Lugs
- Locked Bearing Indicator: Locked Bearing
- Motor Lead Exit: KO Box
- Motor Lead Quantity/Wire: Size 9 @ 10 AWG
- Motor Lead Termination: Flying Leads
- Motor Standards: NEMA
- Motor Type: 0950M
- Number of Poles: 2
- Overall Length: 24.70 in
- Power Factor: 89
- Product Family: General Purpose
- Pulley End Bearing Type: Ball
- Pulley Face Code: Standard
- Pulley Shaft Indicator: Standard
- Rodent Screen: None
- Service Factor: 1.15
- Shaft Diameter: 1.625 in
- Shaft Extension Location: Pulley End
- Shaft Ground Indicator: No Shaft Grounding
- Shaft Rotation: Reversible
- Shaft Slinger Indicator: Shaft Slinger
- Speed: 3,520 rpm
- Speed Code: Single Speed
- Starting Method: Direct on line
- Thermal Device - Bearing: NONE (OLD)
- Thermal Device - Winding: None
- Vibration Sensor Indicator: No Vibration Sensor
- Winding Thermal 1: None
- Winding Thermal 2: None
