AUTOMATIC VALVE P1405GAWR-DBAY 3/2 SOLENOID VALVE
Quick Overview
Manufactured By: AUTOMATIC VALVE
Manufacturer Part Number: P1405GAWR-DBAY
IMS Product Code: 1736767
Packaging: Sold Individually
Description:
Automatic Valve P1405GAWR-DBAY 3/2 Solenoid Valve
- 1/4", 3/8", 1/2", 3/4", 1", 1-1/4" & 1-1/2" port options
- Air pilot & solenoid pilot options
- Single 2/2 & 3/2 options
- Weather-Proof options are NEMA 4X rated
- Explosion-Proof options are CSA & FM approved and ATEX Compliant
Specifications:
- Port Size: 1/2" NPT
- Body Type: Inline
- Valve Function: Single 3/2
- Default Position: Normally Closed
- Actuation: Solenoid
- Series: P14
- Return Type: Spring Return
- Application: Explosion-Proof
- Voltage: 24 VDC
- Electrical Connection: NA
- Valve Body Material: Aluminum
- Hazardous Class: CSA and FM approved
- Class I, Division 1 Groups: A, B, C, D
- Class I, Division 2 Groups: A, B, C, D
- Class II, III, Division 1 Groups: E, F, G
- Class II, III, Division 2 Groups: E, F, G
- ATEX Compliance: CL. I, Zone1 ExmIIT4: AExmII
- NEMA Rating: NEMA 4, 4X, 7C, 7D, 9
- Flow Cv l/min: Cv 7.4 (l/min 7282)
- Weight: 5.1 Lbs (2.31 Kg)
Direct From Manufacturer:
A new product, shipped directly from the manufacturer.
Lead Time: 5 to 7 Days
