ALTEC AIR UA75A-1 NON-CYCLING REFRIGERATED AIR DRYER 115 VAC
Starting At: $1,969.83
Quick Overview
Manufactured By: ALTEC AIR
Manufacturer Part Number: UA75A-1
IMS Product Code: 1929582
Packaging: Sold Individually
Description:
Refrigerated Dryer-Non Cycling 75 scfm
Features:
- Outlet Dewpoint With 100°f / 38°c Saturated Inlet
- 38°f Pressure Dewpoint (pdp)
- Maximum Pressure - 232 Psig
- Maximum Inlet Temperature - 120°f / 49°c
- Voltage: 115VAC-1PH-60HZ
- Voltage Range: 103-127
- RLA: 5.82
- LRA: 32
- Min. Circuit Amp: 7.86
- Max. Fuse Size: 15
- Max. Inlet Air Temp - F: 110
- Min/max Ambient Temp - F: 145/110
- Ref. System Design - PSIG: 150/300
- Suction / Discharge - PSIG: 30/115
- Ref. Compressor Hp: 1/3
- Refrigerant Type: R134A
- Refrigerant Charge: 8 OZ
- Max Air Pressure - PSIG: 232
- Inlet / Outlet Port - NPT: 1" NPT
Direct From Manufacturer:
A new product, shipped directly from the manufacturer.
Lead Time: 3 to 5 Days
